Automatic Bar Feeder Parts BARLOAD

BARLOAD 7# Revolving Tip (Rotating)

Model : BARLOAD 7#
  • Product Specification

    Revolvint tip size: Φ7.0mm~Φ8.0mm

    Product Code Model OD L Tooth gaugeL Push rod tooth gauge
    RB08 7# 7.0mm 57.5mm M4P0.7 M6P0.75
    RB09 7.5# 7.5mm 57.5mm M4P0.7 M6*1.0
    RB10 7# 8mm 57.5mm M4P0.7 M6P0.75
